HP Premium Gloss Cast Overlaminate
When lasting durability counts, you’re protected
Improve quality and durability
Protect your printed graphics with this high gloss overlaminate for indoor and outdoor signs and vehicle graphics. HP Premium Gloss Cast Overlaminate enhances the printed image and provides the utmost protection.
REACH compliant1
Offer a vinyl that complies with high health standards. HP Premium Gloss Cast Overlaminate is REACH compliant1—a regulation of the European Union adopted to improve the protection of human health and the environment from risks that can be posed by chemicals. With an end-to-end approach, the HP Latex printing system continues to drive a greater sustainable impact in large-format printing.
Enjoy easy installation and clean removal Pair HP Premium Gloss Cast Overlaminate with HP Premium Gloss Cast Air GRP for a complete solution. Its air-release channels simplify installation and allow for clean removal for up to two years.
| Target customers | Applications | Benefits |
|---|---|---|
| Print service providers | Overlaminate solution | High-performance cast vinyl to use as an overlaminate for enhancement and protection. |
| Indoor and outdoor signage | Adds durability and helps with handling of cast vinyl. | |
| Vehicle graphics |
Technical Specifications
| Thickness (base vinyl) | 50 microns/2 mil per ISO 20534 Test Method |
| Base vinyl | Clear Cast vinyl with UV inhibitors |
| Liner | 120 g/m² clay coated kraft paper |
| Adhesive | Clear, permanent pressure-sensitive adhesive |
| Adhesive Strength | 16 N/25mm on SS (FINAT FTM1) |
| Finish | Gloss, >80 gloss units at 60˚ reflection |
| Minimum application temperature | 4 to 35˚C (39 to 95˚F) on clean, dry surfaces |
| Service temperature | −40 to 65˚C (−40˚F to 149˚F) |
| Operating temperature | 15 to 35˚C (59 to 95˚F) |
| Operating humidity | 40 to 60% RH |
| Lamination | Cold lamination |
| Storage temperature | 21 to 23˚C (69 to 75˚F) |
| Storage humidity | 50% RH |
| Shelf life | 2 years, unopened in original packaging |
| Environmental | REACH compliant<sup>1</sup> |
| Core size | 3-in core |
| Country of origin | Product of the United States |
Ordering Information
| Product Number | Roll Sizes | UPC | Region |
|---|---|---|---|
| D88ZQA | 1372 mm x 45,7 m (54 in x 150 ft) | 848412028942 | United States, Canada, and Latin America |
| D88ZRA | 1524 mm x 45,7 m (60 in x 150 ft) | 848412028959 | United States, Canada, and Latin America |
Warranty Statement
HP large format printing materials are free from defects in materials and workmanship. For warranty statement, please see HPLFMedia.com/go/mediawarranties. To obtain warranty service, please contact Brand Management Group customer support at HPLFMedia.com/hp/en/contactus.
Footnotes1 See the HP REACH Article 33 Declaration published at HP Printing Products and Consumable Supplies.
